Diaphragm Compressor – L Series
- Structural form: L-type
- Number of compression stages: two-stage
- Cooling method: circulating water cooling
- Operating voltage: 380V Compression medium: high-purity gas, inert gas, flammable and explosive gas, toxic gas, special gas
- Pressure range: inlet pressure, outlet pressure
| Model | Input Pressure MPa(G) |
Output Pressure MPa(G) |
Nominal volume flow Nm3/h |
Rate of capacity (kW) |
Motor Speed r/min |
GL4-770/6-20 | 0.6 | 2 | 770 | 55 | 400 |
| GL4-3000/170-220 | 17 | 22 | 3000 | 37 | 400 |
| GL4-2115/24.9-35 | 2.49 | 3.5 | 2115 | 55 | 430 |
| GL4-160/1.5-64 | 0.15 | 6.4 | 160 | 55 | 400 |
| GL4-100/4.5-250 | 0.45 | 25 | 100 | 45 | 400 |
| GL3-800/300-700 | 30 | 70 | 800 | 45 | 400 |
| GL3-110/3-25 | 0.3 | 2.5 | 110 | 22 | 430 |
| GL3-120/0.2-4 | 0.02 | 0.4 | 120 | 18.5 | 400 |
| GL3-100/10-200 | 1 | 20 | 100 | 30 | 400 |
| GL3-170/2.5-14 | 0.25 | 1.4 | 170 | 22 | 400 |
| GL3-400/20-45 | 2 | 4.5 | 400 | 30 | 400 |
| GL1-3/4-160 | 0.4 | 16 | 3 | 4 | 300 |
| GL1-10/7-150 | 0.7 | 15 | 10 | 4 | 450 |
| GL1-10/4-160 | 0.4 | 16 | 10 | 4 | 400 |
| GL1-4/5-220 | 0.5 | 22 | 4 | 3 | 300 |
| GL1-5/200 | ordinary pressure | 20 | 5 | 3 | 600 |
